SAS330 Lay-On C-Profile
Lay-On Tile and Exposed C-Profile Suspended Ceiling System
A robust product utilizing the strength and design flexibility of rolled steel c-profiles
Delivering unsurpassed creative potential, SAS330 ceiling tiles can be curved, coffered, extra large and and polygonal shape. An exposed grid system, this popular product utilizes the strength and design flexibility of rolled steel c-profiles that support lay-on tiles and an array of electrical service integrations. This system is available in plain, perforated acoustic, wood-effect, mesh, fabric, PPC, and true metal finishes.
SPECIFICATION
Exposed grid.
Lay-In C-Profile
A-D
Acoustic absorption
15-41dB
Acoustic insulation
Lift & tilt access
Tile size up-to
W: 41″
L: 10′
With a total max tile area of: 10ft2
1.8lbs/ft2
System weight
25+
Years life expectancy
Custom specifications are available, please contact our team.
EXAMPLE CONFIGURATIONS & SHAPES
FEATURES
Everything you need to specify
Download our drawings and documents for more detailed technical information about this system. For bespoke configurations, sizes and shapes, please reach out to our Design team for consultation.
- Technical Drawings (PDF)
- CAD Drawings (DWG)
- BIM Files
- COSHH Details
- EPD – SAS Chilled Tiles
- EPD – SAS Horizon – Aluminum
- EPD – SAS Horizon – Steel
- Cradle to Cradle Silver – Full Scope Certificate
- Cradle to Cradle Silver – Material Health Certificate
Our systems are tested to the highest international standards for fire rating. This includes up to A2-s1, d0 to EN 13501-1 and Class A to ASTM E84-18 / UL723. For specific details on performance, please download the datasheet for this system.
We are proudly at the forefront of responsible and sustainable practices in our sector. SAS integrates sustainability into every phase of our operations, from design and sourcing to production and installation. SAS integrates sustainability into every phase of our operations, from design and sourcing to production and installation.
Max 1m² (larger sizes and shapes available with Design consultation)
Metal is our core material; built to last and repurpose. We understand that sustainability in construction demands a long term outlook. It’s why SAS has committed to a circularity mindset. All of our products can be cleaned, reused and recycled.
Radiant heating and cooling panels are durable and visually indistinguishable from a standard aluminum ceiling panel. Using water as the heat transfer medium, heat is either absorbed from or radiated into occupied space as water flows through the system. Excellent thermal comfort is achieved for the occupants due to low air movement. Contact our Design team to find out more.
SYSTEM DRAWINGS
Cross-section – System detail
System detail – Profile choices
Isometric (Linear) – Perspective view
Isometric (Tartan) – Perspective view
RAL COLORS
ALTERNATIVE FINISHES
